As a supplier to the window manufacturer, Ventana is only indirectly involved in the installation of the components. However, through constant dialogue with our industry partners and the client, we are able to provide the ideal installation solution for a range of building types, from solid construction and double-shell masonry to timber-framed structures.
Schüco FD 75
| Profile system: | Schüco FD 75 |
| Panel dimensions: | 500 mm x 900 mm, installation depth: 75 mm |
| Sill type: | Schüco, new-build sill with stop |
| Roll-over resistance class: | 1 |
| Fittings: | Schüco |
| Handle: | ? |
| Corner finish: | Corner connector |
| Colour: | DB 703 FS |
Special features
- New-build threshold with stop, 4 threshold variants possible
- With Roma quadro external blinds box/installed in air gap
- Fixed to VBH CF
- Plaster facade
PremiDoor 76 Profine
| Profile system: | PremiDoor 76 Profine Stemeseder perfect |
| Panel dimensions: | 500 mm x 900 mm |
| Threshold design: | PremiDoor, PD76 Profine with Stemeseder tread plate |
| Roll-over resistance class: | 4 |
| Fittings: | / |
| Handle: | / |
| Corner finish: | V-groove on the inside, welded facing shell on the outside |
| Colour: | Colour DB703 FS |
Special features:
- Aluminium cover Stemeseder
- with Stemeseder box at the top and Stadur VB
- Wooden façade
Gealan 9000
| Profile system: | Gealan 9000 |
| Panel dimensions: | 500 mm x 900 mm |
| Threshold design: | Siegenia Eco Pass with minimal step height |
| Roll-over resistance class: | 4 |
| Fittings: | / |
| Handle: | / |
| Corner finish: | V-groove |
| Colour: | 9016 |
Special features:
- with Beck and Heun box and suggested Stabilum bracket
- Clinker
Rehau Synego
| Profile system: | Rehau Synego |
| Panel dimensions: | 500 mm x 900 mm |
| Sill design: | Siegenia Eco Pass |
| Roll-over resistance class: | 3 |
| Fittings: | / |
| Handle: | / |
| Corner finish: | V-groove |
| Colour: | 9016 |
Special features:
- with Roma Puro external blind box
- Plastered façade
